LCN 2014-STD RH 695 Concealed Overhead Closer DKBRZ
LCN 2014-STD RH 695 Overhead Conceal Closer DKBRZ offers a robust solution for those seeking a heavy-duty concealed door closer. This right-handed model features a dark bronze finish and is part of the 2010 Series, designed specifically for seamless integration into door frames, requiring a minimum 4″ x 4″ tube for installation. Crafted with a durable cast iron body and all-weather fluid, it ensures reliable performance in various conditions, making it suitable for both commercial and residential applications. The single lever arm and roller assembly guarantee smooth and quiet door control, enhancing user experience. This closer is adaptable for aluminum, hollow metal, or wood doors and frames, accommodating interior doors up to 5’0″ and exterior doors up to 4’0″.With a 15-year limited warranty, LCN stands behind the quality of its products. The standard model comes equipped with a metal finish plate and a complete screw pack for easy installation. Additionally, it meets ADA requirements, ensuring accessibility for all users. Optional finishes and custom powder coatings are available, along with an SRI primer for installations in corrosive environments. Choose the LCN 2014-STD RH for durability and aesthetic appeal in your door hardware solutions.
Overhead Conceal Closer DKBRZ
Standard Track Door Closer, Right Hand, Dark Bronze
The 2010 Series is a heavy duty concealed door closer designed to provide complete concealment. The single lever arm and roller assembly provide smooth, quiet door control. The 2010 Series features a cast iron body with all weather fluid. Designed to be concealed in the fram, it requires a minimum 4 In. x 4 In. tube.
The 2010 Series by LCN is a concealed heavy duty closer.
The 2010 Series is designed to provide complete concealment.The single lever arm and roller assembly provide smooth, quiet door control and the choice of finishes and track functions meet virtually all architectural requirements.
- Standard 2010 series closer shipped with standard arm, standard track, metal finish plate and wood and machine screw pack
- Sized cylinders for interior doors to 5’0” and exterior doors to 4’0”
- Handed for right or left swinging doors
- For aluminum, hollow metal, or wood, doors and frames
- Aluminum frame requires minimum 4” x 4” (102 mm) tube
- Closers to meet ADA requirements
- Standard or optional custom powder coat finish
- Optional plated finish on arm, fasteners and finish plate
- Optional SRI primer for installations in corrosive conditions
Attributes
Manufacturer surcharge: 4.5%
Baa Qualified: Yes
Base Material: Varies
Cold Weather Fluid: Yes
Commercial Residential: Commercial
Degree Swing: 180 Deg.
Finish: 695
Finish Family: Dark Bronze
Grade: Grade 1
Handing: Right-Handed
Hold Open: No
Installation: Commercial
Limited Warranty: 15 Years
Mounting Group: Hydraulic
Mounting Location: Header
Pack Qty: 1
Series: 2010 Series Concealed Closers
Ship Weight: 13 lbs.
Subtype: Concealed-in-Door Closers
Type: Concealed Overhead
Unit of Measure: Each
Resources
- 2010 Series Concealed Closers Cut Sheet
- LCN 2010 Series Installation Guide
- LCN Closers & Auto Operators Installation Guide
- LCN Concealed Closer Series Product Guide
- LCN Concealed Closers Catalog
- Overhead Concealed Closer Cross-Reference Sheet
- Von Duprin Finishes Chart
